Key Features
- Universal Input Range 90Vac~264Vac
- Continuous Short Circuit Protection
- Over Voltage Protection
- Meet CEC & ErP Level V1
- Input Plugs can be changed and Replaced for various countries/regions
| Output Voltage | Output Current | Ripple & Noise (Note 2) | Voltage Accuracy (Note 1) | Line Regulation (Note 3) | Load Regulation (Note 4) | Max Output Powe |
| 3.6V - 5.0V | 1200mA | 250mA | ±5%. | ±2%. | ±5%. | 6.0W |
| 5.1V - 6.0V | 1000mA | 250mA | ±5%. | ±2%. | ±5%. | 6.0W |
| 7.0 V - 12V | 660mA | 250mA | ±5%. | ±2%. | ±5%. | 6.0W |
Spec
Connection : Plug In
Type : AC, DC
5W 電源適配器, 可換腳 : Input voltage: 90~264Vac, Hold-up Time: 10ms typ.@ 115Vac, Hi-pot: Input to output= 3,000VAC, Safety: UL/CUL 60950, GB4943, J60950, K60950, IEC/EN/AS/NZA60950/6006, MTBF: MIL-HDBK-217F, GB, at 25℃ / 115VAC...50Khrs min.
